Description
AVAILALE AT: SHIPPENVILLE, PA
STANDARD FEATURES
- W/ Aluminum Wheels
- NATM Certified
- Extruded Aluminum Tube Frame: Durable, Lightweight
- Wishbone Tongue for Superior Support
- 3-Year Structural Warranty
- LED Lighting
- Sealed Plug and Play Wiring Harness
- 15” Steel Wheel with Radial Tire
- Dexter 3,500 lb. 4” Drop Spring Axles
- 1,000 lb. Swivel Jack w/wheel
- Treated Wood Decking
- Rear, Removeable 2-position Ramp
- Spring Loaded Gate Latch
- Aluminum Through-Bolted Greaseable Hinge
- 3 Tie-Down Points
| SPECIFICATIONS | |
|---|---|
| Deck (Length/Width) | 120″ / 60″ |
| Overall (Length/Width) | 162″ / 78″ |
| Crossmembers | 24″ On-Center |
| Frame | 3″ Tube |
| Decking | Treated Wood |
| Deck Height | 17″ |
| Rail Height (above deck) | 13″ |
| ATP Side Walls | Optional |
| Rear Ramp | 4′ Standard |
| Suspension | Double Eye Spring |
| Axle(s) (Qty/Rating) | (1) 3,500 lb. idler |
| Wheels | 15″ Steel |
| Tires | ST205/75R 15 C Radial |
| GVWR | 2,990 lb. |
| Curb Weight | 500 lb. |
| Payload Capacity | 2,490 lb. |
| Coupler Rating / Ball Size | 3,200 lb. / 2″ Ball |
| Hitch Height | 14″ |
| Power Connection | 4-Way Flat |
| Lights | LED |
| Wheel Jack | Standard |
| Safety Chains | 3,200 lb. / 24″ |
