Description
AVAILABLE AT: CORSICA, PA
STANDARD SPECIFICATIONS
GVWR 16,000 lbs
Tare Weights 24’6″ – 3105 lbs
Deck Length 24’6″
Deck Width 97 3/4″ (102″ including pockets and rub rail)
Floor 2 1/4″ Height extruded aluminum plank
Beavertail 51″; 13 1/2″ drop
Frame 10 3/8″ Channel
Axles 7K Dexter torsion ride
Wheels 16″ Steel
Tires 235/80R16
Coupler 2 5/16″ Adjustable 15K ball coupler
Stake Pockets 2″ × 4″ Stake pockets with rub rail both sides
Ramps 60″L × 16″W fold-up ramps (tube frame with angle cross
members). Ramps are pinned in the upright position with
aluminum bars; positions are adjustable for various track widths
Tie Downs (4) Relocatable D-rings
Landing Leg 12K Side crank with drop-leg
Lighting LED oval stop/tail/turn lights, 1″ round LED clearance and
marker lights
Electrical 7-Pin RV plug; breakaway ki
